2500KG Automatic Spring Making Machine 4-7 Roll With Servo Motor System

Name: 2500KG Automatic Spring Making Machine 47 Roll With Servo Motor System
Brand: ZOLYTECH
Price: 1 USD

2500KG Automatic Spring Making Machine 4-7 Roll With Servo Motor System Manufactures

Brand Name : ZOLYTECH

Model Number : S80

Certification : CE

Place of Origin : CHINA

MOQ : 1 pcs

Supply Ability : 30 / pcs / month

Packaging Details : Wooden box

voltage : 380V/50Hz, 220V/60Hz, 3-Phase

Motor power : 5.5KW

Heat treatment power : 15KW

Dimension (L*W*H) : 1500*1500*1600mm

Weight : 2500KG

Capacity : 80pcs/min

Contact Now

High Speed Digital Control Spring Coiling Machine With Servo Motor System

Technical Parameters:

Capacity	80pcs/min
Diameter of wire	1.9-2.4mm
Spring ring	4-7roll
Diameter of spring	62-95mm
Height of spring	80-190mm
voltage	380V/50Hz, 220V/60Hz, 3-Phase

Advantages:

1. It adopts worm and gear decelerator, regulation of speed can be controlled by frequency transformer, lubricating system can be controlled by computer.

2. It is characterized with nice structure, easy adjusting, stable performance, high productivity.

3. This machine is an automatic equipment for making spiral mattress spring. It combines coiling, knotting, heat treatment and out put total four procedures together.

2500KG Automatic Spring Making Machine 4-7 Roll With Servo Motor System
